| Item No. | Dimension（mm) | Cable Size | Dimension（mm) | ||||||
| F | L | W | DФ | CФ | A.W.G | mm2 | Germany | France | |
| EVN0306 | 6.0 | 9.8 | 1.9 | 1.1 | 0.8 | #24 | 0.3 | light blue | pink |
| EVN0308 | 8.0 | 11.8 | |||||||
| EVN0310 | 10.0 | 13.8 | |||||||
| EVN0506 | 6.0 | 12.0 | 2.6 | 1.3 | 1.0 | #22 | 0.5 | orange | white |
| EVN0508 | 8.0 | 14.0 | |||||||
| EVN0510 | 10.0 | 16.0 | |||||||
| EVN0512 | 12.0 | 18.0 | |||||||
| EVN7506 | 6.0 | 12.4 | 2.8 | 1.6 | 1.3 | #20 | 0.75 | white | blue |
| EVN7508 | 8.0 | 14.4 | |||||||
| EVN7510 | 10.0 | 16.4 | |||||||
| EVN7512 | 12.0 | 18.4 | |||||||
| EVN1006 | 6.0 | 12.6 | 3.3 | 1.8 | 1.5 | #18 | 1.0 | yellow | red |
| EVN1008 | 8.0 | 14.6 | |||||||
| EVN1010 | 10.0 | 16.6 | |||||||
| EVN1012 | 12.0 | 18.6 | |||||||
| EVN1508 | 8.0 | 14.8 | 3.7 | 2.0 | 1.7 | #16 | 1.5 | red | black |
| EVN1510 | 10.0 | 16.8 | |||||||
| EVN1512 | 12.0 | 18.8 | |||||||
| EVN1518 | 18.0 | 24.8 | |||||||
| EVN2508 | 8.0 | 15.0 | 4.3 | 2.6 | 2.3 | #14 | 2.5 | blue | gray |
| EVN2510 | 10.0 | 17.0 | |||||||
| EVN2512 | 12.0 | 19.0 | |||||||
| EVN2518 | 18.0 | 25.0 | |||||||
| EVN4009 | 9.0 | 17.0 | 4.9 | 3.2 | 2.8 | #12 | 4.0 | gray | orange |
| EVN4012 | 12.0 | 20.0 | |||||||
| EVN4018 | 18.0 | 26.0 | |||||||
| EVN6010 | 10.0 | 19.5 | 6.0 | 3.9 | 3.5 | #10 | 6.0 | black | green |
| EVN6012 | 12.0 | 21.5 | |||||||
| EVN6018 | 18.0 | 27.5 | |||||||
Terminal Body：Copper
Insulation：Nylon
Temperature：105℃
Plating：Tin
