| Item No | Cable Size AWG | Max Current | Connecting spec. | Thickness(mm) | Dimensions(mm) | Color | |||||
| W | F | L | B | DФ | dФ | ||||||
| MDFN 1.25-187(5) | 0.5~1.5(22~16) | 10A | 0.5×4.8 | 0.5 | 10.4 | 6.8 | 20.4 | 9.6 | 3.6 | 1.7 | Red |
| MDFN 1.25-187(8) | 0.5~1.5(22~16) | 10A | 0.8×4.8 | 0.8 | 10.4 | 6.8 | 20.4 | 9.6 | 3.6 | 1.7 | |
| MDFN 1.25-250 | 0.5~1.5(22~16) | 10A | 0.8×6.35 | 0.8 | 12.3 | 8.6 | 22 | 9.8 | 3.6 | 1.7 | |
| Item No | Cable Size AWG | Max Current | Connecting spec. | Thickness(mm) | Dimensions(mm) | Color | |||||
| W | F | L | B | DФ | dФ | ||||||
| MDFN 2-187(5) | 1.5~2.5(16~14) | 15A | 0.5×4.8 | 0.5 | 10.4 | 6.3 | 20.4 | 10.0 | 4.3 | 2.3 | Blue |
| MDFN 2-187(8) | 1.5~2.5(16~14) | 15A | 0.8×4.8 | 0.8 | 10.4 | 6.3 | 20.4 | 10.0 | 4.3 | 2.3 | |
| MDFN 2-250 | 1.5~2.5(16~14） | 15A | 0.8×6.35 | 0.8 | 12.4 | 8.6 | 22 | 10.0 | 4.5 | 2.3 | |
| Item No | Cable Size AWG | Max Current | Connecting spec. | Thickness(mm) | Dimensions(mm) | Color | |||||
| W | F | L | B | DФ | dФ | ||||||
| MDFN 5.5-250 | 4~6(12~10) | 24A | 0.8×6.35 | 0.8 | 12.3 | 7.7 | 21.8 | 10.0 | 6.5 | 3.4 | Yellow |
